DBG COMBI IV LEFT LED Rear Lamp w/ Triangle Reflex [Fly Lead]
DBG COMBI IV LEFT LED Rear Lamp w/ Triangle Reflex [Fly Lead]
DBG COMBI IV Series LED Rear Combination Lights w/ Triangle Reflex | 252mm
DBG COMBI IV LEFT LED Rear Lamp w/ Triangle Reflex [Fly Lead]
DBG COMBI IV LEFT LED Rear Lamp w/ Triangle Reflex [Fly Lead]
DBG COMBI IV Series LED Rear Combination Lights w/ Triangle Reflex | 252mm

DBG COMBI IV Series LED Rear Combination Trailer Light | 5 Function | 252mm | 12/24V | Fly Lead | Left | Pack of 1 - [334.074]

Stock Code: 334.074

Barcode:

Supplier Part Number:

Minimum Quantity:

From inc VAT (%) VAT n/a Call Free
Discount:
Price inc VAT (%):
VAT n/a:

DBG COMBI IV Series LED Rear Combination Trailer Light | 5 Function | 252mm | 12/24V | Fly Lead | Left | Pack of 1 - [334.074]

Wiring Instructions:

  • Black - Negative/Earth
  • Purple/Green - Reverse
  • Green/Brown - Indicator
  • Red - Fog
  • Green - Tail
  • Red/Blue - Stop
Lamp FunctionCombination | 5 Function
ConnectorFly Lead
Voltage12V, 24V
TechnologyLED
Position on VehicleLeft
Approvals/ComplianceUNECE (for regulatory needs)
Number of Functions6
List of FunctionsStop, Tail, Indicator, Reverse, Fog, Reflector
Voltage Range12-24V
ConnectionFly Lead
Cable Length500mm
TechnologyLED
Position on VehicleLeft Hand
Mounting OptionSurface Mount, 2x Bolts 152mm apart
Item Dimensions252mm (l) x 133mm (w) x 28.5mm (d)
ApprovalsECE R7, R6, R23, R3, R38, R10 (EMC)
IP RatingIP67
Operating Temperature-30°C to +50°C
BrandDun-Bri Group
RangeCOMBI IV
Manufacturer's Part Number (s)334.074
Manufacturer's Warranty1 Year
